Rexroth A10VSOSeries 32 Axial Piston Variable Pump
I-BOETH BOLE HYDRAULIC A10VSO10 REXROTH hydraulic piston pump
For machines with medium pressure requirements
A10VSO18 A10VSO28 A10VSO45 A10VSO71 A10VSO100 A10VSO140 A10VSO180
Nominal pressure 250 bar
Maximum pressure 315 bar
Open circuit
● Through drive for mounting of further pumps up to same nominal size
● Approved for high speeds
● Low operating noise
● Controls with short response times
● Large variety of controls
● High power density
● Swashplate design
Hydraulic fluidsTechnical data
Operating pressure range
DR – Pressure control
DRG – Pressure control, remotely operated
DRF (DFR) / DRS (DFR1) / DRSC- Pressure and flov
control
ED Electro-hydraulic pressure control
ER – Electro-hydraulic pressure control
EP – Electro-proportional control
EK – Electro-proportional controlwith controller cut-off
EP(K).DF/ EP(K).DS/EP(K)with pressure and flow control
LA… – Pressure, flow and power controller
EP.ED / EK.ED – with electro-hydraulic
Product Detai
Rexroth A10VSOSeries 32 Axial Piston Variable Pump
I-BOETH BOLE HYDRAULIC A10VSO10 REXROTH hydraulic piston pump
For machines with medium pressure requirements
A10VSO18 A10VSO28 A10VSO45 A10VSO71 A10VSO100 A10VSO140 A10VSO180
Nominal pressure 250 bar
Maximum pressure 315 bar
| Size | A10VO A10VSO10 | A10VO A10VSO18 | A10VO A10VSO28 | A10VO A10VSO45 | A10VO A10VSO60 | A10VO A10VSO63 | |||
| Displacement geometric, per revolution | Vg max | cm³ | 10.5 | 18 | 28 | 45 | 60 | 63 | |
| Nominal pressure | pnom | bar | 250 | 250 | 250 | 250 | 250 | 250 | |
| Maximum pressure | pmax | bar | 315 | 315 | 315 | 315 | 315 | 315 | |
| Maximum speed 1) | at Vg max | nnom | rpm | 3600 | 3300 | 3000 | 2600 | 2600 | 2600 |
| Flow | at Vg max and nnom | qV nom | l/min | 37 | 59 | 84 | 117 | 156 | 163 |
| at Vg max and n = 1500 rpm | qV 1500 | l/min | 15 | 27 | 42 | 68 | 90 | 95 | |
| Power | at qV nom and pnom | P | kW | 16 | 25 | 35 | 49 | 65 | 68 |
| at qV 1500 and pnom | P 1500 | kW | 7 | 11 | 18 | 28 | 37 | 39 | |
| Torque | at Vg max and pnom | M | Nm | 42 | 71 | 111 | 179 | 238 | 250 |
Technical Data
