H1T053 / H1T045 Tandem Axial Piston Pump

Application Range and Technical Specifications

Danfoss H1T Tandem Axial Piston Pump series pumps are high-performance closed circuit variable displacement axial piston tandem pumps designed for mobile hydraulic applications. The H1T045 and H1T053 models use a cradle swash plate design, providing high efficiency, compact structure, excellent controllability, and reliable operation under demanding working conditions.

The tandem configuration integrates two variable displacement pump sections in one housing, allowing independent hydraulic circuits or combined power transmission systems. This design makes H1T pumps especially suitable for hydrostatic drive systems requiring high power density, precise control, and long service life.

1. H1T045 Technical Specifications

Product Overview

The H1T045 is a medium displacement tandem axial piston pump with a maximum displacement of 45.0 cm³/rev (2.75 in³/rev). It is designed for compact and medium-size mobile equipment where efficient hydrostatic transmission, smooth speed control, and high reliability are required.

The pump provides excellent response characteristics through advanced displacement control options, including electronic displacement control (EDC), forward-neutral-reverse control (FNR), and manual displacement control versions.

Technical Parameters

Parameter Specification
Model H1T045
Pump Type Closed Circuit Variable Displacement Tandem Axial Piston Pump
Design Cradle Swash Plate Design
Displacement 45.0 cm³/rev
Displacement 2.75 in³/rev
Flow Rate at Rated Speed 153 L/min
Maximum Theoretical Torque 0.80 N·m/bar
Dry Weight Approx. 65 kg
Rotation Direction CW / CCW available
Circuit Type Closed Loop Hydrostatic Drive
Control Options EDC, FNR, MDC, NFPE
Mounting Flange SAE B type
Port Connection SAE O-ring Boss
Installation Flexible mounting position
Application Type Mobile hydraulic equipment

H1T045 Application Range

The H1T045 is widely used in medium-power hydrostatic transmission systems where compact dimensions and precise control are important.

Main Applications:

1. Construction Machinery

H1T045 provides stable hydraulic power transmission for:

  • Compact wheel loaders
  • Skid steer loaders
  • Mini loaders
  • Small road rollers
  • Compact construction vehicles

Its high response speed allows operators to achieve smooth acceleration, accurate speed adjustment, and improved machine productivity.

2. Agricultural Machinery

The pump is suitable for:

  • Harvesting machines
  • Self-propelled agricultural equipment
  • Sprayers
  • Tractors with hydrostatic drive systems

The variable displacement function enables efficient power management, reducing fuel consumption while maintaining working performance.

3. Material Handling Equipment

Applications include:

  • Forklifts
  • Telescopic handlers
  • Industrial transport vehicles

The H1T045 offers precise low-speed control and high torque capability, which is important for vehicles requiring frequent starting, stopping, and direction changes.

4. Municipal and Special Vehicles

Typical applications:

  • Sweepers
  • Utility vehicles
  • Maintenance vehicles
  • Autonomous mobile platforms

H1T053 Technical Specifications

Product Overview

The H1T053 is the higher displacement version of the H1T045, offering increased hydraulic output capacity with a displacement of 53.8 cm³/rev (3.28 in³/rev). It delivers higher flow and torque capability for machines requiring greater traction force and higher productivity.

Compared with H1T045, the H1T053 provides approximately 20% higher displacement, making it suitable for medium and heavy-duty mobile equipment requiring increased hydraulic power.

Technical Parameters

Parameter Specification
Model H1T053
Pump Type Closed Circuit Variable Displacement Tandem Axial Piston Pump
Design Cradle Swash Plate Design
Displacement 53.8 cm³/rev
Displacement 3.28 in³/rev
Flow Rate at Rated Speed 183 L/min
Maximum Theoretical Torque 0.90 N·m/bar
Dry Weight Approx. 65 kg
Rotation Direction CW / CCW available
Circuit Type Closed Loop Hydrostatic Drive
Control Options EDC, FNR, MDC, NFPE
Mounting Flange SAE B type
Port Connection SAE O-ring Boss
Application Type Medium and heavy mobile machinery

H1T053 Application Range

The H1T053 is designed for applications requiring higher hydraulic power output and stronger hydrostatic transmission capability.

1. Medium and Heavy Construction Equipment

Common applications:

  • Wheel loaders
  • Excavators with hydrostatic drive systems
  • Road construction machinery
  • Asphalt pavers
  • Compactors
  • Drilling equipment

The higher displacement provides increased torque output, allowing machines to operate efficiently under heavy loads.

2. Mining and Heavy-Duty Equipment

H1T053 is suitable for:

  • Mining vehicles
  • Underground transportation equipment
  • Heavy-duty loaders
  • Special industrial machines

Its robust design provides reliable operation under continuous high-load conditions.

3. Forestry Machinery

Applications include:

  • Forestry harvesters
  • Timber handling equipment
  • Logging machines

The pump provides high starting torque and excellent control performance for machines working in variable terrain.

4. Agricultural and Harvesting Equipment

Typical applications:

  • Large combines
  • Self-propelled harvesters
  • High-power agricultural machines

The high flow capacity improves machine speed and working efficiency.

Comparison Between H1T045 and H1T053

Item H1T045 H1T053
Displacement 45.0 cm³/rev 53.8 cm³/rev
Flow Capacity 153 L/min 183 L/min
Torque Capability 0.80 N·m/bar 0.90 N·m/bar
Power Level Medium Medium-high
Machine Size Compact / medium equipment Medium / heavy equipment
Fuel Efficiency Excellent Excellent under higher loads
Response Fast Fast
Main Advantage Compact and efficient Higher output and stronger traction
Recommended Use Small-medium hydrostatic drives Higher power hydrostatic drives

11174972 H1-T-053-R-A-M-N-A5-C2-N-E7-F-G1-H3-38-38-38-38-N-P-22-PN-C07-NNN H1T053RAMNA5C2NE7FG1H338383838NP22PNC07NNN
1401734 H1-T-053-R-A-A-N-A2-C3-N-E7-F-G5-NN-30-30-30-30-N-P-20-PN-C03-NNN H1T053RAANA2C3NE7FG5NN30303030NP20PNC03NNN
1401736 H1-T-053-R-A-A-N-A2-C3-N-E7-F-G1-H3-35-35-35-35-N-P-20-PN-NNN-NNN H1T053RAANA2C3NE7FG1H335353535NP20PNNNNNNN
80005491 H1-T-053-R-A-A-A-A2-C2-B-E7-F-G5-NN-42-42-38-38-N-P-20-PN-C04-NNN H1T053RAAAA2C2BE7FG5NN42423838NP20PNC04NNN
80005703 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G5-H3-23-23-23-23-N-P-28-PN-NNN-NNN H1T053RAANA4C3NE7FG5H323232323NP28PNNNNNNN
80006492 H1-T-053-R-A-A-N-A2-C2-B-D1-F-G5-H3-35-35-35-35-N-P-24-PN-NNN-NNN H1T053RAANA2C2BD1FG5H335353535NP24PNNNNNNN
83002103 H1-T-053-R-A-A-N-A2-C1-N-D1-F-G1-H3-25-25-25-25-N-P-24-PN-NNN-NNN H1T053RAANA2C1ND1FG1H325252525NP24PNNNNNNN
83002374 H1-T-053-R-A-A-N-A4-C2-N-E7-F-G1-H3-30-30-20-38-N-P-24-PN-NNN-NNN H1T053RAANA4C2NE7FG1H330302038NP24PNNNNNNN
83002883 H1-T-053-R-A-A-A-A2-C1-N-E7-F-G5-NN-40-40-20-20-N-P-20-PN-NNN-NNN H1T053RAAAA2C1NE7FG5NN40402020NP20PNNNNNNN
83003316 H1-T-053-R-A-A-N-A5-C1-N-E7-F-G5-H2-35-35-35-35-N-P-24-PN-NNN-NNN H1T053RAANA5C1NE7FG5H235353535NP24PNNNNNNN
83003445 H1-T-053-R-A-A-N-A5-C1-B-E7-F-G5-H3-35-35-35-35-N-P-26-PN-NNN-NNN H1T053RAANA5C1BE7FG5H335353535NP26PNNNNNNN
83004422 H1-T-053-R-A-A-N-A4-C2-N-E7-F-G1-H3-30-30-38-20-N-P-24-PN-NNN-NNN H1T053RAANA4C2NE7FG1H330303820NP24PNNNNNNN
83006085 H1-T-053-R-A-A-N-A5-C2-N-E7-F-G1-H5-38-38-38-38-N-P-24-PN-NNN-NNN H1T053RAANA5C2NE7FG1H538383838NP24PNNNNNNN
83006134 H1-T-053-R-A-A-N-A5-C1-B-E7-F-G5-H3-35-35-35-35-N-P-26-PN-C10-NNN H1T053RAANA5C1BE7FG5H335353535NP26PNC10NNN
83006372 H1-T-053-R-A-A-N-A5-C1-B-E7-F-G5-H3-35-35-35-35-N-P-26-PN-C10-NNN H1T053RAANA5C1BE7FG5H335353535NP26PNC10NNN
83007284 H1-T-053-R-A-A-N-A4-C2-B-E7-F-G1-T3-35-35-35-35-M-P-20-PN-NNN-S01 H1T053RAANA4C2BE7FG1T335353535MP20PNNNNS01
83007351 H1-T-053-R-A-A-A-A2-C1-N-E7-F-G1-NN-35-35-35-35-N-P-20-PN-NNN-NNN H1T053RAAAA2C1NE7FG1NN35353535NP20PNNNNNNN
83007649 H1-T-053-R-A-A-N-A2-C1-N-E7-F-G1-H2-25-25-25-25-N-P-20-PN-NNN-NNN H1T053RAANA2C1NE7FG1H225252525NP20PNNNNNNN
83007914 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G8-H8-38-38-38-38-N-P-28-PN-C07-NNN H1T053RAANA2C3ND1FG8H838383838NP28PNC07NNN
83007915 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G8-H8-35-35-35-35-N-P-24-PN-C07-NNN H1T053RAANA2C3ND1FG8H835353535NP24PNC07NNN
83007934 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G7-H7-35-35-35-35-N-P-28-PN-C01-NNN H1T053RAANA2C3ND1FG7H735353535NP28PNC01NNN
83009790 H1-T-053-R-A-A-N-A2-C2-N-E7-F-G1-H5-38-38-38-38-N-P-24-PN-NNN-NNN H1T053RAANA2C2NE7FG1H538383838NP24PNNNNNNN
83010942 H1-T-053-R-A-A-N-A2-C2-N-E7-F-G6-H3-28-28-25-25-N-P-20-PN-NNN-NNN H1T053RAANA2C2NE7FG6H328282525NP20PNNNNNNN
83012499 H1-T-053-R-A-A-N-A5-C3-N-E7-F-G5-NN-30-30-30-30-N-P-20-PN-NNN-NNN H1T053RAANA5C3NE7FG5NN30303030NP20PNNNNNNN
83012760 H1-T-053-R-A-A-N-B1-C3-B-E7-F-G5-NN-30-30-30-30-N-P-20-PN-C03-E03 H1T053RAANB1C3BE7FG5NN30303030NP20PNC03E03
83015150 H1-T-053-R-A-A-N-A2-C2-N-D1-F-G1-TN-33-33-33-33-M-P-24-PN-NNN-S02 H1T053RAANA2C2ND1FG1TN33333333MP24PNNNNS02
83016784 H1-T-053-R-A-A-N-B1-C3-B-E7-F-G5-NN-30-30-30-30-N-P-20-PN-C03-E06 H1T053RAANB1C3BE7FG5NN30303030NP20PNC03E06
83019768 H1-T-053-R-A-A-N-A2-C1-B-D1-F-G1-H3-38-38-38-38-N-P-28-PN-NNN-E10 H1T053RAANA2C1BD1FG1H338383838NP28PNNNNE10
83020365 H1-T-053-R-A-A-N-A3-C1-N-E7-F-G5-H2-28-28-28-28-N-P-24-PN-NNN-NNN H1T053RAANA3C1NE7FG5H228282828NP24PNNNNNNN
83023245 H1-T-053-R-A-A-N-A2-C1-N-D1-F-G1-H3-38-38-38-38-N-P-28-PN-NNN-NNN H1T053RAANA2C1ND1FG1H338383838NP28PNNNNNNN
83023494 H1-T-053-R-A-A-N-A4-C1-N-E7-F-G5-NN-30-30-30-30-N-P-24-PN-NNN-NNN H1T053RAANA4C1NE7FG5NN30303030NP24PNNNNNNN
83023692 H1-T-053-R-A-A-N-B1-C1-B-E7-F-G1-TN-18-18-15-15-M-P-20-PN-NNN-S01 H1T053RAANB1C1BE7FG1TN18181515MP20PNNNNS01
83023802 H1-T-053-R-A-A-N-A4-C2-B-E7-F-G1-H1-38-38-38-38-N-P-24-PN-NNN-NNN H1T053RAANA4C2BE7FG1H138383838NP24PNNNNNNN
83024137 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G7-H7-35-35-35-35-N-P-28-PN-C01-NNN H1T053RAANA2C3ND1FG7H735353535NP28PNC01NNN
83024451 H1-T-053-R-A-A-A-A4-C2-N-E7-F-G1-H5-28-28-35-35-N-P-20-PN-NNN-NNN H1T053RAAAA4C2NE7FG1H528283535NP20PNNNNNNN
83024699 H1-T-053-R-A-A-N-A8-C2-C-E7-F-G6-H3-38-38-38-38-N-P-24-P1-NNN-NNN H1T053RAANA8C2CE7FG6H338383838NP24P1NNNNNN
83025483 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G5-H3-25-25-25-25-N-P-28-PN-NNN-NNN H1T053RAANA4C3NE7FG5H325252525NP28PNNNNNNN
83027994 H1-T-053-R-A-A-N-A5-C1-N-E7-F-G5-NN-30-30-30-30-N-P-20-PN-C03-NNN H1T053RAANA5C1NE7FG5NN30303030NP20PNC03NNN
83028153 H1-T-053-R-A-A-N-A2-C2-N-E7-F-G1-TN-35-35-35-35-M-P-32-PN-NNN-S02 H1T053RAANA2C2NE7FG1TN35353535MP32PNNNNS02
83029168 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G1-H3-30-30-30-30-N-P-28-PN-NNN-NNN H1T053RAANA4C3NE7FG1H330303030NP28PNNNNNNN
83029774 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G8-H8-38-38-38-38-N-P-24-PN-C07-NNN H1T053RAANA2C3ND1FG8H838383838NP24PNC07NNN
83029814 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G8-H8-35-35-35-35-N-P-24-PN-C07-NNN H1T053RAANA2C3ND1FG8H835353535NP24PNC07NNN
83031847 H1-T-053-R-A-A-N-A2-C2-N-E7-F-G6-H3-28-28-35-25-N-P-20-PN-NNN-NNN H1T053RAANA2C2NE7FG6H328283525NP20PNNNNNNN
83032674 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G5-H3-38-38-38-38-N-P-24-PN-NNN-NNN H1T053RAANA4C3NE7FG5H338383838NP24PNNNNNNN
83032785 H1-T-053-R-A-A-N-A4-C1-N-E7-F-G5-H2-35-35-35-35-N-P-24-PN-NNN-NNN H1T053RAANA4C1NE7FG5H235353535NP24PNNNNNNN
83036091 H1-T-053-R-A-A-N-B1-C3-B-E7-F-G5-NN-30-30-30-30-N-P-20-PN-C03-E10 H1T053RAANB1C3BE7FG5NN30303030NP20PNC03E10
83036201 H1-T-053-R-A-A-A-D7-C1-B-E7-F-G6-H3-30-30-35-35-N-P-24-P3-NNN-NNN H1T053RAAAD7C1BE7FG6H330303535NP24P3NNNNNN
83036371 H1-T-053-R-A-A-N-A5-C2-N-E7-F-G5-T3-30-30-30-30-M-P-24-PN-NNN-S01 H1T053RAANA5C2NE7FG5T330303030MP24PNNNNS01
83037789 H1-T-053-R-A-A-N-A3-C2-N-E7-F-G1-T2-35-35-35-35-M-P-32-PN-NNN-S02 H1T053RAANA3C2NE7FG1T235353535MP32PNNNNS02
83038317 H1-T-053-R-A-A-N-A5-C1-B-F7-F-G5-H3-35-35-35-35-N-P-26-PN-C10-NNN H1T053RAANA5C1BF7FG5H335353535NP26PNC10NNN
83038353 H1-T-053-R-A-A-N-A5-C1-N-E7-F-G1-TN-28-28-25-25-M-P-24-P3-NNN-S01 H1T053RAANA5C1NE7FG1TN28282525MP24P3NNNS01
83039746 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G5-H3-35-35-35-35-N-P-26-PN-NNN-NNN H1T053RAANA2C3ND1FG5H335353535NP26PNNNNNNN
83039932 H1-T-053-R-A-A-N-A5-C2-N-E7-F-G1-H3-38-38-38-38-N-P-22-PN-C07-NNN H1T053RAANA5C2NE7FG1H338383838NP22PNC07NNN
83040779 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G5-H3-35-35-35-35-N-P-24-PN-NNN-NNN H1T053RAANA4C3NE7FG5H335353535NP24PNNNNNNN
83041346 H1-T-053-R-A-A-N-A5-C2-N-F7-F-G5-H2-35-35-35-35-N-P-24-PN-NNN-NNN H1T053RAANA5C2NF7FG5H235353535NP24PNNNNNNN
83043322 H1-T-053-R-A-A-N-A4-C2-N-E7-F-G1-T3-23-23-23-23-M-P-24-PN-NNN-S01 H1T053RAANA4C2NE7FG1T323232323MP24PNNNNS01
83044011 H1-T-053-R-A-A-N-A2-C3-N-E7-F-G5-T3-28-28-28-28-M-P-24-PN-NNN-S01 H1T053RAANA2C3NE7FG5T328282828MP24PNNNNS01
83044329 H1-T-053-R-A-A-N-A4-C1-N-E7-F-G1-T3-35-35-35-35-M-P-24-PN-NNN-S01 H1T053RAANA4C1NE7FG1T335353535MP24PNNNNS01
83044352 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G5-H3-30-30-30-30-N-P-24-PN-NNN-NNN H1T053RAANA4C3NE7FG5H330303030NP24PNNNNNNN
83045708 H1-T-053-R-A-A-N-A2-C3-N-E7-F-G1-H3-30-30-30-30-N-P-20-PN-C07-NNN H1T053RAANA2C3NE7FG1H330303030NP20PNC07NNN
83046942 H1-T-053-R-A-A-N-A2-C3-N-E7-F-G1-H3-30-30-20-20-N-P-20-PN-C07-NNN H1T053RAANA2C3NE7FG1H330302020NP20PNC07NNN
83047041 H1-T-053-R-A-A-N-A4-C3-N-D1-J-G5-H3-38-38-38-38-N-P-28-P4-NNN-NNN H1T053RAANA4C3ND1JG5H338383838NP28P4NNNNNN
83047180 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G7-H7-38-38-38-38-N-P-28-PN-C01-NNN H1T053RAANA2C3ND1FG7H738383838NP28PNC01NNN
83047385 H1-T-053-R-A-A-N-A2-C3-N-E7-F-G1-H3-33-33-23-23-N-P-20-PN-C07-NNN H1T053RAANA2C3NE7FG1H333332323NP20PNC07NNN
83047445 H1-T-053-R-A-A-N-A3-C3-N-E7-F-G5-TN-38-38-38-38-M-P-24-PN-NNN-S01 H1T053RAANA3C3NE7FG5TN38383838MP24PNNNNS01
83047446 H1-T-053-R-A-A-N-A3-C3-N-E7-F-G5-TN-38-38-38-38-M-P-24-PN-NNN-S02 H1T053RAANA3C3NE7FG5TN38383838MP24PNNNNS02
83047985 H1-T-053-R-A-A-N-B1-C3-B-E7-F-G5-NN-30-30-30-30-N-P-20-PN-C03-NNN H1T053RAANB1C3BE7FG5NN30303030NP20PNC03NNN
83048136 H1-T-053-R-A-A-A-A5-C1-N-E7-F-G1-TN-28-28-35-35-M-P-24-PN-NNN-S01 H1T053RAAAA5C1NE7FG1TN28283535MP24PNNNNS01
83048499 H1-T-053-R-A-A-N-A5-C1-N-E7-F-G1-TN-28-28-35-35-M-P-24-PN-NNN-S01 H1T053RAANA5C1NE7FG1TN28283535MP24PNNNNS01
83048878 H1-T-053-R-A-A-A-A4-C2-N-E7-F-G5-T3-23-23-23-23-M-P-24-PN-NNN-S01 H1T053RAAAA4C2NE7FG5T323232323MP24PNNNNS01
83048987 H1-T-053-R-A-A-N-A4-C2-N-E7-F-G5-T3-23-23-23-23-M-P-24-PN-NNN-S01 H1T053RAANA4C2NE7FG5T323232323MP24PNNNNS01
83048988 H1-T-053-R-A-A-N-A5-C2-N-E7-F-G5-T3-23-23-23-23-M-P-24-PN-NNN-S01 H1T053RAANA5C2NE7FG5T323232323MP24PNNNNS01
83049627 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G5-H3-38-38-23-23-N-P-24-PN-NNN-NNN H1T053RAANA4C3NE7FG5H338382323NP24PNNNNNNN
83050035 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G5-H3-38-38-25-25-N-P-24-PN-NNN-NNN H1T053RAANA4C3NE7FG5H338382525NP24PNNNNNNN
83050215 H1-T-053-R-A-A-N-A2-C3-N-E7-F-G7-H8-38-38-38-38-N-P-28-PN-NNN-NNN H1T053RAANA2C3NE7FG7H838383838NP28PNNNNNNN
83050421 H1-T-053-R-A-A-N-A3-C2-N-E7-F-G1-T2-35-35-35-35-M-P-24-PN-NNN-S02 H1T053RAANA3C2NE7FG1T235353535MP24PNNNNS02
83050514 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G8-H7-35-35-35-35-N-P-24-PN-C07-NNN H1T053RAANA2C3ND1FG8H735353535NP24PNC07NNN
83051704 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G5-H3-28-28-28-28-N-P-28-PN-NNN-NNN H1T053RAANA4C3NE7FG5H328282828NP28PNNNNNNN
83053601 H1-T-053-R-A-A-N-M1-C1-N-E7-F-G5-T3-35-35-35-35-M-P-20-PN-NNN-S01 H1T053RAANM1C1NE7FG5T335353535MP20PNNNNS01
83054294 H1-T-053-R-A-A-N-A2-C3-N-E7-F-G5-NN-30-30-30-30-N-P-20-PN-NNN-NNN H1T053RAANA2C3NE7FG5NN30303030NP20PNNNNNNN
83055792 H1-T-053-R-A-A-N-A4-C2-N-E7-F-G1-T2-25-25-25-25-M-P-24-PN-NNN-S01 H1T053RAANA4C2NE7FG1T225252525MP24PNNNNS01
83056719 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G5-H3-30-30-30-30-N-P-28-PN-NNN-NNN H1T053RAANA4C3NE7FG5H330303030NP28PNNNNNNN
83057036 H1-T-053-R-A-A-A-M1-C2-B-E7-F-G5-H3-38-38-38-38-N-P-24-PN-NNN-NNN H1T053RAAAM1C2BE7FG5H338383838NP24PNNNNNNN
83058803 H1-T-053-R-A-A-A-A3-C3-N-E7-F-G5-T2-35-35-35-38-M-P-26-PN-NNN-S01 H1T053RAAAA3C3NE7FG5T235353538MP26PNNNNS01
83059364 H1-T-053-R-A-A-N-A4-C3-N-E7-F-G1-H3-38-38-38-38-N-P-24-PN-NNN-NNN H1T053RAANA4C3NE7FG1H338383838NP24PNNNNNNN
83059828 H1-T-053-R-A-A-N-A5-C2-N-E7-F-G1-TN-35-35-35-35-M-P-24-PN-NNN-S01 H1T053RAANA5C2NE7FG1TN35353535MP24PNNNNS01
83060444 H1-T-053-R-A-A-A-A2-C2-N-E7-F-G5-H2-35-35-35-35-N-P-26-PN-NNN-NNN H1T053RAAAA2C2NE7FG5H235353535NP26PNNNNNNN
83064616 H1-T-053-R-A-A-N-A4-C1-N-D1-F-G5-H2-38-20-38-20-N-P-24-PN-NNN-NNN H1T053RAANA4C1ND1FG5H238203820NP24PNNNNNNN
83069514 H1-T-053-R-A-A-A-A4-C1-N-E7-F-G5-T2-33-33-28-28-M-P-20-PN-NNN-S01 H1T053RAAAA4C1NE7FG5T233332828MP20PNNNNS01
83069515 H1-T-053-R-A-A-N-A4-C2-N-E7-F-G1-NN-25-25-25-25-N-P-24-PN-NNN-NNN H1T053RAANA4C2NE7FG1NN25252525NP24PNNNNNNN
83085576 H1-T-053-R-A-A-N-A4-C1-N-D1-F-G5-H2-38-20-20-38-N-P-24-PN-NNN-NNN H1T053RAANA4C1ND1FG5H238202038NP24PNNNNNNN
83085896 H1-T-053-R-A-A-N-A2-C3-N-D1-F-G6-H3-35-35-35-35-N-P-34-PN-NNN-NNN H1T053RAANA2C3ND1FG6H335353535NP34PNNNNNNN
83086203 H1-T-053-R-A-A-N-H3-C3-N-E7-F-G5-NN-40-40-40-40-N-P-24-PN-NNN-NNN H1T053RAANH3C3NE7FG5NN40404040NP24PNNNNNNN



H1T053L

Артикул Полный код Полный код
80006656 H1-T-053-L-A-A-N-A2-C2-N-D1-F-G1-H3-38-38-38-38-N-P-24-PN-NNN-NNN H1T053LAANA2C2ND1FG1H338383838NP24PNNNNNNN
83005145 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G1-H2-30-30-30-30-N-P-24-PN-NNN-NNN H1T053LAANA5C2NE7FG1H230303030NP24PNNNNNNN
83007300 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G1-H2-28-28-28-28-N-P-20-PN-NNN-NNN H1T053LAANA5C2NE7FG1H228282828NP20PNNNNNNN
83007622 H1-T-053-L-A-A-N-A2-C2-N-E7-F-G1-H3-38-38-38-38-N-P-24-PN-NNN-NNN H1T053LAANA2C2NE7FG1H338383838NP24PNNNNNNN
83008706 H1-T-053-L-A-A-N-A4-C1-N-E7-F-G1-H3-33-33-33-33-N-P-24-PN-NNN-NNN H1T053LAANA4C1NE7FG1H333333333NP24PNNNNNNN
83010567 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G5-T3-28-28-28-28-M-P-24-PN-NNN-S01 H1T053LAANA5C2NE7FG5T328282828MP24PNNNNS01
83012587 H1-T-053-L-A-A-N-A4-C2-N-E7-F-G1-H3-35-35-35-35-N-P-30-PN-NNN-NNN H1T053LAANA4C2NE7FG1H335353535NP30PNNNNNNN
83014362 H1-T-053-L-A-A-N-A5-C2-N-F7-F-G1-TN-33-33-33-33-M-P-24-PN-NNN-S01 H1T053LAANA5C2NF7FG1TN33333333MP24PNNNNS01
83018592 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G1-NN-38-38-38-38-N-P-24-PN-C10-NNN H1T053LAANA5C2NE7FG1NN38383838NP24PNC10NNN
83024463 H1-T-053-L-A-A-N-A4-C2-N-D1-F-G1-NN-33-33-33-33-N-P-24-PN-NNN-NNN H1T053LAANA4C2ND1FG1NN33333333NP24PNNNNNNN
83027670 H1-T-053-L-A-A-N-A5-C3-N-F7-F-G5-TN-33-38-38-38-M-P-24-PN-NNN-S02 H1T053LAANA5C3NF7FG5TN33383838MP24PNNNNS02
83027924 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G1-T2-20-20-20-20-M-P-24-PN-NNN-S02 H1T053LAANA5C2NE7FG1T220202020MP24PNNNNS02
83029504 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G1-T2-38-28-38-28-M-P-24-PN-NNN-S01 H1T053LAANA5C2NE7FG1T238283828MP24PNNNNS01
83031344 H1-T-053-L-A-A-N-A2-C1-N-E7-F-G5-TN-23-23-23-23-M-P-22-PN-NNN-S01 H1T053LAANA2C1NE7FG5TN23232323MP22PNNNNS01
83032557 H1-T-053-L-A-A-N-A5-C2-B-F7-F-G1-NN-38-38-38-38-N-P-24-PN-NNN-NNN H1T053LAANA5C2BF7FG1NN38383838NP24PNNNNNNN
83032727 H1-T-053-L-A-A-N-A4-C3-B-E7-F-G1-TN-30-30-30-30-M-P-28-PN-NNN-S01 H1T053LAANA4C3BE7FG1TN30303030MP28PNNNNS01
83032780 H1-T-053-L-A-A-N-B1-C2-B-E7-F-G1-T2-20-20-20-20-M-P-24-PN-NNN-S02 H1T053LAANB1C2BE7FG1T220202020MP24PNNNNS02
83040124 H1-T-053-L-A-A-N-A5-C2-B-F7-F-G5-NN-38-38-38-38-N-P-24-PN-NNN-NNN H1T053LAANA5C2BF7FG5NN38383838NP24PNNNNNNN
83040716 H1-T-053-L-A-A-N-A4-C2-N-E7-F-G1-TN-25-25-33-33-M-P-30-PN-NNN-S01 H1T053LAANA4C2NE7FG1TN25253333MP30PNNNNS01
83042101 H1-T-053-L-A-A-N-A4-C2-N-E7-F-G5-TN-28-28-30-30-M-P-30-PN-NNN-S01 H1T053LAANA4C2NE7FG5TN28283030MP30PNNNNS01
83042297 H1-T-053-L-A-A-N-A2-C1-N-E7-F-G1-H3-38-38-38-38-N-P-24-PN-NNN-NNN H1T053LAANA2C1NE7FG1H338383838NP24PNNNNNNN
83042910 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G1-T2-38-28-28-38-M-P-24-PN-NNN-S01 H1T053LAANA5C2NE7FG1T238282838MP24PNNNNS01
83044414 H1-T-053-L-A-A-N-A5-C3-N-E7-F-G1-H3-35-35-35-35-N-P-24-PN-NNN-NNN H1T053LAANA5C3NE7FG1H335353535NP24PNNNNNNN
83048696 H1-T-053-L-A-A-A-A4-C2-N-D1-F-G1-H5-35-35-30-30-N-P-20-PN-NNN-NNN H1T053LAAAA4C2ND1FG1H535353030NP20PNNNNNNN
83048809 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G1-H5-38-38-38-38-N-P-30-PN-C03-NNN H1T053LAANA5C2NE7FG1H538383838NP30PNC03NNN
83048846 H1-T-053-L-A-A-N-A5-C2-B-E7-F-G1-H5-38-38-38-38-N-P-30-PN-C03-NNN H1T053LAANA5C2BE7FG1H538383838NP30PNC03NNN
83050179 H1-T-053-L-A-A-N-A2-C3-N-E7-F-F2-H3-38-38-38-38-N-P-28-PN-NNN-NNN H1T053LAANA2C3NE7FF2H338383838NP28PNNNNNNN
83050745 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G5-T3-35-35-35-35-M-P-24-PN-NNN-S01 H1T053LAANA5C2NE7FG5T335353535MP24PNNNNS01
83050999 H1-T-053-L-A-A-N-A5-C1-N-E7-F-G5-TN-23-23-23-23-M-P-20-PN-NNN-S01 H1T053LAANA5C1NE7FG5TN23232323MP20PNNNNS01
83054408 H1-T-053-L-A-A-A-A4-C3-B-E7-F-G1-TN-38-38-20-20-M-P-20-PN-NNN-S04 H1T053LAAAA4C3BE7FG1TN38382020MP20PNNNNS04
83054776 H1-T-053-L-A-A-A-A4-C3-B-E7-F-G1-TN-38-38-25-25-M-P-20-PN-NNN-S04 H1T053LAAAA4C3BE7FG1TN38382525MP20PNNNNS04
83054931 H1-T-053-L-A-A-A-A4-C2-B-E7-F-G1-TN-38-38-25-25-M-P-20-PN-NNN-S04 H1T053LAAAA4C2BE7FG1TN38382525MP20PNNNNS04
83055134 H1-T-053-L-A-A-N-A4-C3-N-E7-F-G1-TN-38-38-20-20-M-P-20-PN-NNN-S04 H1T053LAANA4C3NE7FG1TN38382020MP20PNNNNS04
83055135 H1-T-053-L-A-A-N-A4-C2-N-E7-F-G1-TN-38-38-25-25-M-P-20-PN-NNN-S04 H1T053LAANA4C2NE7FG1TN38382525MP20PNNNNS04
83056358 H1-T-053-L-A-A-N-A3-C1-N-E7-F-G1-NN-38-38-38-38-N-P-24-PN-NNN-NNN H1T053LAANA3C1NE7FG1NN38383838NP24PNNNNNNN
83058140 H1-T-053-L-A-A-N-A5-C2-N-E7-F-G1-TN-35-35-35-35-M-P-24-PN-NNN-S01 H1T053LAANA5C2NE7FG1TN35353535MP24PNNNNS01
83061665 H1-T-053-L-A-A-N-D7-C1-N-E7-F-G1-TN-38-38-25-25-M-P-20-PN-NNN-S04 H1T053LAAND7C1NE7FG1TN38382525MP20PNNNNS04
83064786 H1-T-053-L-A-A-N-A4-C1-N-E7-F-G1-TN-38-38-25-25-M-P-20-PN-NNN-S04 H1T053LAANA4C1NE7FG1TN38382525MP20PNNNNS04







H1T045R

Артикул Полный код Полный код
1400730 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G7-H7-35-35-35-35-N-P-28-PN-C01-NNN H1T045RAANA2C3ND1FG7H735353535NP28PNC01NNN
1400734 H1-T-045-R-A-A-N-A2-C3-B-D1-F-G5-H3-30-30-18-18-N-P-20-PN-NNN-NNN H1T045RAANA2C3BD1FG5H330301818NP20PNNNNNNN
1400740 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G5-H3-35-35-35-35-N-P-28-PN-NNN-NNN H1T045RAANA2C3ND1FG5H335353535NP28PNNNNNNN
80001649 H1-T-045-R-A-A-N-A4-C3-N-D1-F-G5-H1-25-25-25-25-N-P-22-PN-NNN-NNN H1T045RAANA4C3ND1FG5H125252525NP22PNNNNNNN
80001660 H1-T-045-R-A-A-N-A2-C3-N-E7-F-G1-H3-42-42-42-42-N-P-20-PN-NNN-NNN H1T045RAANA2C3NE7FG1H342424242NP20PNNNNNNN
80003566 H1-T-045-R-A-A-N-A3-C3-N-E7-F-G1-H3-38-38-38-38-N-P-24-PN-NNN-NNN H1T045RAANA3C3NE7FG1H338383838NP24PNNNNNNN
80003682 H1-T-045-R-A-A-N-A2-C3-N-E7-F-G5-NN-38-38-38-38-N-P-30-PN-NNN-NNN H1T045RAANA2C3NE7FG5NN38383838NP30PNNNNNNN
80005155 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H5-38-38-38-38-N-P-20-PN-NNN-NNN H1T045RAANA4C2NE7FG1H538383838NP20PNNNNNNN
83001435 H1-T-045-R-A-A-N-A2-C1-N-E7-F-G5-H5-35-35-35-35-N-P-34-PN-NNN-NNN H1T045RAANA2C1NE7FG5H535353535NP34PNNNNNNN
83002407 H1-T-045-R-A-A-N-A2-C3-N-E7-F-G1-H3-33-33-33-33-N-P-24-PN-NNN-NNN H1T045RAANA2C3NE7FG1H333333333NP24PNNNNNNN
83002782 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H3-38-38-38-38-N-P-20-PN-NNN-NNN H1T045RAANA4C2NE7FG1H338383838NP20PNNNNNNN
83004249 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H1-38-38-38-38-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG1H138383838NP24PNNNNNNN
83004299 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-T1-38-38-38-38-M-P-24-PN-NNN-S02 H1T045RAANA4C2NE7FG1T138383838MP24PNNNNS02
83004317 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G5-NN-42-42-18-18-N-P-20-PN-NNN-NNN H1T045RAANA2C3ND1FG5NN42421818NP20PNNNNNNN
83004763 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H1-30-30-35-20-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG1H130303520NP24PNNNNNNN
83004911 H1-T-045-R-A-A-N-A4-C3-N-E7-F-G1-H3-33-33-33-33-N-P-24-PN-NNN-NNN H1T045RAANA4C3NE7FG1H333333333NP24PNNNNNNN
83005196 H1-T-045-R-A-A-N-A5-C2-N-E7-F-G5-H3-25-25-25-25-N-P-30-PN-NNN-NNN H1T045RAANA5C2NE7FG5H325252525NP30PNNNNNNN
83006360 H1-T-045-R-A-A-N-A4-C2-B-E7-F-G5-H2-35-35-35-35-N-P-24-PN-NNN-NNN H1T045RAANA4C2BE7FG5H235353535NP24PNNNNNNN
83006561 H1-T-045-R-A-A-N-A4-C3-N-E7-F-G1-H3-30-30-35-35-N-P-24-PN-NNN-NNN H1T045RAANA4C3NE7FG1H330303535NP24PNNNNNNN
83007197 H1-T-045-R-A-A-N-A5-C2-B-F7-F-G5-T3-42-42-42-42-M-P-24-PN-NNN-S02 H1T045RAANA5C2BF7FG5T342424242MP24PNNNNS02
83007283 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G7-H7-40-40-40-40-N-P-28-PN-C01-NNN H1T045RAANA2C3ND1FG7H740404040NP28PNC01NNN
83007326 H1-T-045-R-A-A-N-A3-C2-N-E7-F-G5-H3-30-30-30-30-N-P-20-PN-NNN-NNN H1T045RAANA3C2NE7FG5H330303030NP20PNNNNNNN
83007916 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G8-H8-35-35-35-35-N-P-24-PN-C07-NNN H1T045RAANA2C3ND1FG8H835353535NP24PNC07NNN
83007935 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G7-H7-35-35-35-35-N-P-28-PN-C01-NNN H1T045RAANA2C3ND1FG7H735353535NP28PNC01NNN
83007936 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G7-H7-33-33-33-33-N-P-28-PN-C01-NNN H1T045RAANA2C3ND1FG7H733333333NP28PNC01NNN
83009296 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G5-T3-30-30-30-30-M-P-20-PN-NNN-S01 H1T045RAANA4C2NE7FG5T330303030MP20PNNNNS01
83009558 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H3-30-30-38-20-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG1H330303820NP24PNNNNNNN
83011327 H1-T-045-R-A-A-N-A3-C3-N-F7-F-G5-H3-35-35-35-35-N-P-28-PN-NNN-NNN H1T045RAANA3C3NF7FG5H335353535NP28PNNNNNNN
83014568 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H3-20-20-20-20-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG1H320202020NP24PNNNNNNN
83015037 H1-T-045-R-A-A-N-NN-C3-D-E7-F-G1-H5-38-38-38-38-N-P-30-P1-NNN-E05 H1T045RAANNNC3DE7FG1H538383838NP30P1NNNE05
83015045 H1-T-045-R-A-A-N-A4-C1-N-D1-F-G1-H3-38-38-38-38-N-P-24-PN-C13-NNN H1T045RAANA4C1ND1FG1H338383838NP24PNC13NNN
83015061 H1-T-045-R-A-A-N-A4-C3-N-D1-F-G5-H5-30-30-30-30-N-P-20-PN-NNN-NNN H1T045RAANA4C3ND1FG5H530303030NP20PNNNNNNN
83017168 H1-T-045-R-A-A-N-A3-C1-N-E7-F-G5-H2-33-33-33-33-N-P-24-PN-NNN-NNN H1T045RAANA3C1NE7FG5H233333333NP24PNNNNNNN
83017739 H1-T-045-R-A-A-N-A4-C3-N-D1-F-G1-T3-25-25-25-25-M-P-22-PN-NNN-S01 H1T045RAANA4C3ND1FG1T325252525MP22PNNNNS01
83017784 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G5-NN-42-42-42-42-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG5NN42424242NP24PNNNNNNN
83018805 H1-T-045-R-A-A-N-B5-C3-C-D1-F-G7-H7-35-35-35-35-N-P-28-P1-C01-NNN H1T045RAANB5C3CD1FG7H735353535NP28P1C01NNN
83018953 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H3-33-33-33-33-N-P-20-PN-NNN-NNN H1T045RAANA4C2NE7FG1H333333333NP20PNNNNNNN
83019122 H1-T-045-R-A-A-N-A2-C1-B-D1-F-G1-H3-38-38-38-38-N-P-24-PN-C13-E08 H1T045RAANA2C1BD1FG1H338383838NP24PNC13E08
83019729 H1-T-045-R-A-A-N-A3-C3-N-F7-F-G7-H7-40-40-40-40-N-P-28-PN-C01-NNN H1T045RAANA3C3NF7FG7H740404040NP28PNC01NNN
83019766 H1-T-045-R-A-A-N-A2-C1-B-D1-F-G1-H3-38-38-38-38-N-P-28-PN-C13-E08 H1T045RAANA2C1BD1FG1H338383838NP28PNC13E08
83019767 H1-T-045-R-A-A-N-A2-C1-B-D1-F-G1-H3-38-38-38-38-N-P-28-PN-C13-E09 H1T045RAANA2C1BD1FG1H338383838NP28PNC13E09
83020080 H1-T-045-R-A-A-N-A4-C1-N-E7-F-G5-H1-30-30-30-30-N-P-24-PN-NNN-NNN H1T045RAANA4C1NE7FG5H130303030NP24PNNNNNNN
83021009 H1-T-045-R-A-A-N-A4-C1-N-E7-F-G1-T3-20-20-20-20-M-P-24-PN-NNN-S01 H1T045RAANA4C1NE7FG1T320202020MP24PNNNNS01
83021183 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H3-18-28-35-25-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG1H318283525NP24PNNNNNNN
83021744 H1-T-045-R-A-A-N-A5-C1-B-E7-F-G5-H3-35-35-35-35-N-P-26-PN-C10-NNN H1T045RAANA5C1BE7FG5H335353535NP26PNC10NNN
83023246 H1-T-045-R-A-A-N-A2-C1-N-D1-F-G1-H3-38-38-38-38-N-P-28-PN-C13-NNN H1T045RAANA2C1ND1FG1H338383838NP28PNC13NNN
83024134 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G7-H7-40-40-40-40-N-P-28-PN-C01-NNN H1T045RAANA2C3ND1FG7H740404040NP28PNC01NNN
83024138 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G7-H7-35-35-35-35-N-P-28-PN-C01-NNN H1T045RAANA2C3ND1FG7H735353535NP28PNC01NNN
83024139 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G7-H7-33-33-33-33-N-P-28-PN-C01-NNN H1T045RAANA2C3ND1FG7H733333333NP28PNC01NNN
83024147 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H3-23-23-23-23-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG1H323232323NP24PNNNNNNN
83024235 H1-T-045-R-A-A-N-A2-C1-N-E7-F-G5-NN-42-42-42-42-N-P-24-P3-C04-NNN H1T045RAANA2C1NE7FG5NN42424242NP24P3C04NNN
83024577 H1-T-045-R-A-A-N-A4-C3-N-D1-F-G1-H3-25-25-25-25-N-P-22-PN-NNN-NNN H1T045RAANA4C3ND1FG1H325252525NP22PNNNNNNN
83025268 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H3-30-35-30-20-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG1H330353020NP24PNNNNNNN
83029813 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G8-H8-35-35-35-35-N-P-24-PN-C07-NNN H1T045RAANA2C3ND1FG8H835353535NP24PNC07NNN
83030984 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-H3-35-35-35-35-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG1H335353535NP24PNNNNNNN
83031844 H1-T-045-R-A-A-N-A2-C3-B-E7-F-G1-H1-20-20-20-20-N-P-24-PN-NNN-NNN H1T045RAANA2C3BE7FG1H120202020NP24PNNNNNNN
83032815 H1-T-045-R-A-A-N-A5-C2-N-F7-F-G5-H3-30-30-30-30-N-P-24-PN-NNN-NNN H1T045RAANA5C2NF7FG5H330303030NP24PNNNNNNN
83033999 H1-T-045-R-A-A-N-A3-C3-N-F7-F-G5-H3-30-30-30-30-N-P-28-PN-NNN-NNN H1T045RAANA3C3NF7FG5H330303030NP28PNNNNNNN
83035469 H1-T-045-R-A-A-N-A2-C3-N-E7-F-G5-H3-38-38-38-38-N-P-22-PN-NNN-NNN H1T045RAANA2C3NE7FG5H338383838NP22PNNNNNNN
83037070 H1-T-045-R-A-A-N-A4-C3-B-D1-F-G5-T2-35-35-35-35-M-P-24-P3-NNN-S01 H1T045RAANA4C3BD1FG5T235353535MP24P3NNNS01
83038342 H1-T-045-R-A-A-N-A5-C1-B-F7-F-G5-H3-35-35-35-35-N-P-26-PN-C10-NNN H1T045RAANA5C1BF7FG5H335353535NP26PNC10NNN
83039275 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G1-T3-35-35-35-35-M-P-24-PN-NNN-S02 H1T045RAANA4C2NE7FG1T335353535MP24PNNNNS02
83039339 H1-T-045-R-A-A-N-A3-C3-N-F7-F-G7-H7-42-42-42-42-N-P-28-PN-C01-NNN H1T045RAANA3C3NF7FG7H742424242NP28PNC01NNN
83039747 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G5-H3-35-35-35-35-N-P-26-PN-NNN-NNN H1T045RAANA2C3ND1FG5H335353535NP26PNNNNNNN
83040260 H1-T-045-R-A-A-N-A4-C2-N-D1-F-G6-T3-28-28-28-28-M-P-24-PN-NNN-S02 H1T045RAANA4C2ND1FG6T328282828MP24PNNNNS02
83040375 H1-T-045-R-A-A-N-A2-C1-B-D1-F-G5-NN-33-33-33-33-N-P-20-PN-NNN-NNN H1T045RAANA2C1BD1FG5NN33333333NP20PNNNNNNN
83040777 H1-T-045-R-A-A-N-M1-C3-N-D1-F-G5-H3-35-35-35-35-N-P-26-PN-NNN-NNN H1T045RAANM1C3ND1FG5H335353535NP26PNNNNNNN
83041324 H1-T-045-R-A-A-N-A3-C3-N-F7-F-G7-H7-42-42-42-42-N-P-28-PN-C07-NNN H1T045RAANA3C3NF7FG7H742424242NP28PNC07NNN
83041657 H1-T-045-R-A-A-N-A2-C1-N-E7-F-G1-T3-30-30-30-30-M-P-24-PN-NNN-S01 H1T045RAANA2C1NE7FG1T330303030MP24PNNNNS01
83044267 H1-T-045-R-A-A-N-A5-C2-N-F7-F-G5-T3-30-30-30-30-M-P-24-PN-NNN-S01 H1T045RAANA5C2NF7FG5T330303030MP24PNNNNS01
83044303 H1-T-045-R-A-A-N-A5-C2-N-F7-F-G5-T3-30-30-30-30-M-P-24-PN-NNN-S03 H1T045RAANA5C2NF7FG5T330303030MP24PNNNNS03
83045728 H1-T-045-R-A-A-N-A4-C1-N-D1-F-G1-TN-20-20-20-20-M-P-22-PN-NNN-S02 H1T045RAANA4C1ND1FG1TN20202020MP22PNNNNS02
83046658 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G7-H7-40-40-40-40-N-P-30-PN-C01-NNN H1T045RAANA2C3ND1FG7H740404040NP30PNC01NNN
83046839 H1-T-045-R-A-A-N-A2-C1-N-E7-F-G5-H1-35-35-35-35-N-P-20-P3-NNN-NNN H1T045RAANA2C1NE7FG5H135353535NP20P3NNNNNN
83047622 H1-T-045-R-A-A-N-B1-C1-B-E7-F-G5-NN-30-30-30-30-N-P-20-PN-NNN-NNN H1T045RAANB1C1BE7FG5NN30303030NP20PNNNNNNN
83048018 H1-T-045-R-A-A-N-A2-C1-N-E7-F-G5-H1-33-33-33-33-N-P-20-P3-C07-NNN H1T045RAANA2C1NE7FG5H133333333NP20P3C07NNN
83048324 H1-T-045-R-A-A-N-A2-C1-N-E7-F-G1-T3-23-23-23-23-M-P-24-PN-NNN-S01 H1T045RAANA2C1NE7FG1T323232323MP24PNNNNS01
83048644 H1-T-045-R-A-A-N-A2-C3-N-D1-F-G5-NN-42-42-18-18-N-P-24-PN-NNN-NNN H1T045RAANA2C3ND1FG5NN42421818NP24PNNNNNNN
83048911 H1-T-045-R-A-A-N-A2-C1-N-D1-F-G5-H1-25-25-25-25-N-P-20-PN-NNN-NNN H1T045RAANA2C1ND1FG5H125252525NP20PNNNNNNN
83049275 H1-T-045-R-A-A-N-A4-C1-N-D1-F-G1-TN-40-20-40-20-M-P-24-PN-NNN-S01 H1T045RAANA4C1ND1FG1TN40204020MP24PNNNNS01
83052984 H1-T-045-R-A-A-N-A4-C1-N-E7-F-G1-T3-30-30-30-30-M-P-24-PN-NNN-S01 H1T045RAANA4C1NE7FG1T330303030MP24PNNNNS01
83053319 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G6-T3-42-42-42-42-M-P-28-PN-NNN-S01 H1T045RAANA4C2NE7FG6T342424242MP28PNNNNS01
83054559 H1-T-045-R-A-A-N-A2-C3-N-E7-F-G1-T3-42-42-42-42-M-P-24-PN-NNN-S01 H1T045RAANA2C3NE7FG1T342424242MP24PNNNNS01
83054560 H1-T-045-R-A-A-N-A3-C3-N-E7-F-G1-T3-42-42-42-42-M-P-24-PN-NNN-S01 H1T045RAANA3C3NE7FG1T342424242MP24PNNNNS01
83055679 H1-T-045-R-A-A-N-A2-C1-N-E7-F-G5-H1-35-35-35-35-N-P-20-P3-C07-NNN H1T045RAANA2C1NE7FG5H135353535NP20P3C07NNN
83056952 H1-T-045-R-A-A-N-A2-C3-N-E7-F-G5-TN-38-38-38-38-M-P-20-PN-NNN-S01 H1T045RAANA2C3NE7FG5TN38383838MP20PNNNNS01
83057037 H1-T-045-R-A-A-N-M1-C2-B-E7-F-G5-H1-38-38-38-38-N-P-24-PN-NNN-NNN H1T045RAANM1C2BE7FG5H138383838NP24PNNNNNNN
83058149 H1-T-045-R-A-A-N-A4-C1-N-D1-F-G5-TN-40-20-40-25-M-P-24-PN-NNN-S01 H1T045RAANA4C1ND1FG5TN40204025MP24PNNNNS01
83058507 H1-T-045-R-A-A-N-A3-C2-N-E7-F-G1-H3-42-42-42-42-N-P-26-PN-NNN-NNN H1T045RAANA3C2NE7FG1H342424242NP26PNNNNNNN
83064626 H1-T-045-R-A-A-N-NN-C3-C-E7-F-G1-H3-30-30-30-30-N-P-26-P1-NNN-NNN H1T045RAANNNC3CE7FG1H330303030NP26P1NNNNNN
83078034 H1-T-045-R-A-A-N-A4-C2-N-E7-F-G6-H3-42-42-42-42-N-P-24-PN-NNN-NNN H1T045RAANA4C2NE7FG6H342424242NP24PNNNNNNN
83084413 H1-T-045-R-A-A-N-A5-C1-N-E7-F-G1-H2-30-30-28-28-N-P-26-PN-NNN-NNN H1T045RAANA5C1NE7FG1H230302828NP26PNNNNNNN
83085472 H1-T-045-R-A-A-N-A5-C2-N-F7-F-G5-NN-33-33-33-33-N-P-24-PN-NNN-NNN H1T045RAANA5C2NF7FG5NN33333333NP24PNNNNNNN



H1T045L

Артикул Полный код Полный код
1401230 H1-T-045-L-A-A-N-B6-C1-B-E7-F-G5-NN-25-25-40-40-N-P-20-PN-NNN-NNN H1T045LAANB6C1BE7FG5NN25254040NP20PNNNNNNN
1401231 H1-T-045-L-A-A-N-A5-C3-N-E7-F-G8-H8-35-35-35-35-N-P-28-PN-C01-NNN H1T045LAANA5C3NE7FG8H835353535NP28PNC01NNN
1401234 H1-T-045-L-A-A-N-A2-C3-N-D1-F-G5-H2-40-40-40-40-N-P-20-PN-NNN-NNN H1T045LAANA2C3ND1FG5H240404040NP20PNNNNNNN
1401235 H1-T-045-L-A-A-N-A3-C2-N-E7-F-G5-H3-25-25-25-25-N-P-20-PN-NNN-NNN H1T045LAANA3C2NE7FG5H325252525NP20PNNNNNNN
80001588 H1-T-045-L-A-A-N-A2-C2-N-E7-F-G5-NN-42-42-42-42-N-P-20-PN-NNN-NNN H1T045LAANA2C2NE7FG5NN42424242NP20PNNNNNNN
80005833 H1-T-045-L-A-A-N-B6-C1-B-E7-F-G5-NN-25-25-40-40-N-P-20-P3-NNN-NNN H1T045LAANB6C1BE7FG5NN25254040NP20P3NNNNNN
80006449 H1-T-045-L-A-A-N-A5-C1-N-E7-F-G1-H3-35-35-35-35-N-P-24-PN-NNN-NNN H1T045LAANA5C1NE7FG1H335353535NP24PNNNNNNN
80006672 H1-T-045-L-A-A-N-A3-C2-N-E7-F-G1-H2-33-33-33-33-N-P-24-PN-NNN-NNN H1T045LAANA3C2NE7FG1H233333333NP24PNNNNNNN
83001391 H1-T-045-L-A-A-N-A3-C1-N-E7-F-G5-H2-20-20-20-20-N-P-20-PN-NNN-NNN H1T045LAANA3C1NE7FG5H220202020NP20PNNNNNNN
83002908 H1-T-045-L-A-A-N-A3-C2-N-E7-F-G6-H2-35-35-35-35-N-P-24-PN-NNN-NNN H1T045LAANA3C2NE7FG6H235353535NP24PNNNNNNN
83002965 H1-T-045-L-A-A-N-A3-C1-N-E7-F-G5-H2-20-20-20-20-N-P-20-PN-NNN-NNN H1T045LAANA3C1NE7FG5H220202020NP20PNNNNNNN
83005261 H1-T-045-L-A-A-N-A2-C2-N-D1-F-G5-H2-40-40-40-40-N-P-20-PN-NNN-NNN H1T045LAANA2C2ND1FG5H240404040NP20PNNNNNNN
83006643 H1-T-045-L-A-A-N-A2-C2-N-E7-F-G5-NN-42-42-42-42-N-P-20-PN-NNN-NNN H1T045LAANA2C2NE7FG5NN42424242NP20PNNNNNNN
83006667 H1-T-045-L-A-A-N-A4-C1-N-E7-F-G5-T3-35-35-35-35-M-P-24-PN-NNN-S01 H1T045LAANA4C1NE7FG5T335353535MP24PNNNNS01
83007353 H1-T-045-L-A-A-N-A4-C2-N-D1-F-G1-H2-42-42-42-42-N-P-24-PN-NNN-NNN H1T045LAANA4C2ND1FG1H242424242NP24PNNNNNNN
83008415 H1-T-045-L-A-A-N-A4-C1-N-E7-F-G5-TN-23-23-23-23-M-P-24-PN-NNN-S01 H1T045LAANA4C1NE7FG5TN23232323MP24PNNNNS01
83008703 H1-T-045-L-A-A-N-A5-C3-N-E7-F-G8-H8-35-35-35-35-N-P-28-PN-C01-NNN H1T045LAANA5C3NE7FG8H835353535NP28PNC01NNN
83010552 H1-T-045-L-A-A-N-A5-C2-B-E7-F-G5-T2-30-30-30-30-M-P-20-PN-NNN-S03 H1T045LAANA5C2BE7FG5T230303030MP20PNNNNS03
83011730 H1-T-045-L-A-A-N-A5-C2-N-E7-F-G5-NN-28-28-28-28-N-P-20-PN-NNN-NNN H1T045LAANA5C2NE7FG5NN28282828NP20PNNNNNNN
83019496 H1-T-045-L-A-A-N-A5-C3-N-F7-F-G1-H2-35-35-35-35-N-P-24-PN-NNN-NNN H1T045LAANA5C3NF7FG1H235353535NP24PNNNNNNN
83028112 H1-T-045-L-A-A-N-A5-C3-N-E7-F-G8-H8-35-35-35-35-N-P-28-PN-C01-NNN H1T045LAANA5C3NE7FG8H835353535NP28PNC01NNN
83029410 H1-T-045-L-A-A-N-A4-C2-N-E7-F-G1-H3-42-42-42-42-N-P-24-PN-NNN-NNN H1T045LAANA4C2NE7FG1H342424242NP24PNNNNNNN
83029801 H1-T-045-L-A-A-N-A5-C2-N-E7-F-G1-TN-35-35-35-35-M-P-24-PN-NNN-S01 H1T045LAANA5C2NE7FG1TN35353535MP24PNNNNS01
83031347 H1-T-045-L-A-A-N-A4-C1-N-D1-F-G5-H3-25-25-25-25-N-P-28-PN-NNN-NNN H1T045LAANA4C1ND1FG5H325252525NP28PNNNNNNN
83032685 H1-T-045-L-A-A-N-A5-C2-B-F7-F-G5-H2-42-42-42-42-N-P-24-PN-NNN-NNN H1T045LAANA5C2BF7FG5H242424242NP24PNNNNNNN
83036761 H1-T-045-L-A-A-N-A5-C2-N-E7-F-G1-H1-42-42-35-35-N-P-34-PN-NNN-NNN H1T045LAANA5C2NE7FG1H142423535NP34PNNNNNNN
83036762 H1-T-045-L-A-A-N-A5-C2-N-E7-F-G1-NN-42-42-35-35-N-P-34-PN-NNN-NNN H1T045LAANA5C2NE7FG1NN42423535NP34PNNNNNNN
83041086 H1-T-045-L-A-A-N-A2-C2-N-E7-F-G1-TN-38-38-38-38-M-P-24-PN-NNN-S01 H1T045LAANA2C2NE7FG1TN38383838MP24PNNNNS01
83041616 H1-T-045-L-A-A-N-A5-C3-N-F7-F-G1-TN-35-35-35-35-M-P-24-PN-NNN-S01 H1T045LAANA5C3NF7FG1TN35353535MP24PNNNNS01
83041694 H1-T-045-L-A-A-N-A5-C3-N-F7-F-G1-TN-35-35-35-35-M-P-30-PN-NNN-S01 H1T045LAANA5C3NF7FG1TN35353535MP30PNNNNS01
83042100 H1-T-045-L-A-A-N-A2-C1-N-E7-F-G1-H3-40-40-40-40-N-P-30-PN-NNN-NNN H1T045LAANA2C1NE7FG1H340404040NP30PNNNNNNN
83043127 H1-T-045-L-A-A-N-A4-C2-N-E7-F-G1-H3-35-35-35-35-N-P-20-PN-NNN-NNN H1T045LAANA4C2NE7FG1H335353535NP20PNNNNNNN
83046893 H1-T-045-L-A-A-N-A5-C2-N-F7-F-G1-T3-30-30-30-30-M-P-24-PN-NNN-S03 H1T045LAANA5C2NF7FG1T330303030MP24PNNNNS03
83048787 H1-T-045-L-A-A-N-A2-C2-N-E7-F-G5-TN-18-18-18-18-M-P-24-PN-NNN-S01 H1T045LAANA2C2NE7FG5TN18181818MP24PNNNNS01
83049180 H1-T-045-L-A-A-N-A2-C1-N-E7-F-G1-H3-40-40-40-40-N-P-24-P3-NNN-NNN H1T045LAANA2C1NE7FG1H340404040NP24P3NNNNNN
83049245 H1-T-045-L-A-A-N-A2-C3-N-E7-F-F2-H3-35-35-35-35-N-P-28-PN-NNN-NNN H1T045LAANA2C3NE7FF2H335353535NP28PNNNNNNN
83049346 H1-T-045-L-A-A-N-A2-C3-N-E7-F-G1-H3-38-38-38-38-N-P-28-P3-NNN-NNN H1T045LAANA2C3NE7FG1H338383838NP28P3NNNNNN
83054374 H1-T-045-L-A-A-N-A5-C3-N-E7-F-G1-H3-18-18-18-18-N-P-24-PN-NNN-NNN H1T045LAANA5C3NE7FG1H318181818NP24PNNNNNNN
83055642 H1-T-045-L-A-A-N-A2-C2-N-E7-F-G1-H5-18-18-18-18-N-P-24-PN-C07-NNN H1T045LAANA2C2NE7FG1H518181818NP24PNC07NNN
83055773 H1-T-045-L-A-A-N-A2-C2-N-E7-F-G1-H5-23-23-23-23-N-P-24-PN-C07-NNN H1T045LAANA2C2NE7FG1H523232323NP24PNC07NNN
83055801 H1-T-045-L-A-A-N-A3-C1-N-E7-F-G1-H3-38-38-38-38-N-P-24-PN-NNN-NNN H1T045LAANA3C1NE7FG1H338383838NP24PNNNNNNN
83056502 H1-T-045-L-A-A-N-A2-C3-N-E7-F-G1-H3-20-35-28-28-N-P-28-PN-NNN-NNN H1T045LAANA2C3NE7FG1H320352828NP28PNNNNNNN
83056503 H1-T-045-L-A-A-N-A2-C3-N-E7-F-G1-H3-35-35-35-35-N-P-28-PN-NNN-NNN H1T045LAANA2C3NE7FG1H335353535NP28PNNNNNNN
83056527 H1-T-045-L-A-A-N-A5-C2-N-E7-F-G1-T2-35-35-35-35-M-P-30-PN-NNN-S01 H1T045LAANA5C2NE7FG1T235353535MP30PNNNNS01
83056592 H1-T-045-L-A-A-N-A5-C2-N-E7-F-G1-T3-42-42-42-42-M-P-30-PN-NNN-S01 H1T045LAANA5C2NE7FG1T342424242MP30PNNNNS01
83056630 H1-T-045-L-A-A-N-A5-C2-N-E7-F-G6-T3-42-42-42-42-M-P-30-PN-NNN-S01 H1T045LAANA5C2NE7FG6T342424242MP30PNNNNS01
83058971 H1-T-045-L-A-A-N-A2-C1-N-E7-F-G5-NN-42-42-42-42-N-P-20-PN-NNN-NNN H1T045LAANA2C1NE7FG5NN42424242NP20PNNNNNNN

A: We are factory and trading company.

A: Generally it is 3-5 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, it is according to quantity.

A: We can provide samples, but not for free.

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.

If you have more questions, pls feel free to contact us as below:

sales@bailehydraulic.com

WeChat/WhatsApp：0086 18060096097

Related products
